FDD03-05S2
DC / DC converter, 3W, input 18-36V, output 5V / 500mA
- Series: fdd03a
- Min.input voltage, V: 18
- Max input voltage, V: 36
- Rated input voltage, V: 24
- Number of outputs, pcs: 1
- Maximum output current, A: 0.5
- Power, W: 2.5
- Energy Conversion Efficiency (Efficiency),%: 69
- The accuracy of the output voltage,%: 2
- Noise at the exit, mV: 300
- Insulation Voltage, V: 1500
- Operating temperature, C: -40 ... 71
- Design: dip24
- Output voltage, V: 5
- Protection complex: protection against short circuit with auto recovery
- Weight g: fifteen
Inquire Now
Description
Overview:
FDD03-05S2, Number of outputs: 1
Uout = 5V, Iout = 0 ... 0.5A
Power: 3 W
Efficiency: 68%
Ripple (span): 127 mV
Dielectric strength: input-output: 1500 V DC
Input voltage DC: 18 .. .36 V (Rated: 24 V)
Remote control
Protection against: short circuit
FEATURES:
- EFFICIENCY UP TO 79%
- 4:1 & 3:1 & 2:1 WIDE INPUT RANGE
- I/O ISOLATION
- SHORT CIRCUIT PROTECTION
- HIGH PERFORMANCE
- 2 YEARS WARRANTY
| Nom. number | 495345927 |
| Manufacturer | Chinfa Electronics |
| Series | fdd03a |
| Min.input voltage, V | 18 |
| Max input voltage, V | 36 |
| Rated input voltage, V | 24 |
| Number of outputs, pcs | 1 |
| Maximum output current, A | 0.5 |
| Power, W | 2.5 |
| Energy Conversion Efficiency (Efficiency),% | 69 |
| The accuracy of the output voltage,% | 2 |
| Noise at the exit, mV | 300 |
| Insulation Voltage, V | 1500 |
| Operating temperature, C | -40 ... 71 |
| Design | dip24 |
| Output voltage, V | 5 |
| Protection complex | protection against short circuit with auto recovery |
| Weight g | fifteen |
