DRH-120-48
Power supply, input:2 phases 340-550V, output 48B, 2.5A, 120W
- Output voltage, V: 48
- Output current, A: 2.5
- Power, W: 120
- Sizes, mm: 65.5x125.2x100
- Weight g: 760
Inquire Now
Description
Overview:
DRH-120-48, Input voltage AC: 340 ... 550 V (Rated: 380 V / 2 phases)
Input voltage DC: 480 ... 780 V
Number of outputs: 1
Output voltage 48 V
Output current 0 ... 2.5 A
Output power: 120 W
Ripple level (range): 80 mV
Efficiency: 86%
Insulation strength: input-output: 3000 V AC, input-ground: 2000 V AC
Protection against: short circuit, overload, overvoltage, overheating
Dimensions: 65.5 x 125.2 x 100 mm, weight: 0.75 kg
Enclosure: for mounting on a DIN rail
Operating temperature ranges: -20 ... 60 ° C, storage: -40 ... 85 ° C
| Nom. number | 9000113856 |
| Manufacturer | MEAN WELL |
| Output voltage, V | 48 |
| Output current, A | 2.5 |
| Power, W | 120 |
| Sizes, mm | 65.5x125.2x100 |
| Weight g | 760 |
- 3-phase input 340-550VAC
- Short-circuit, overload, over-temperature and over-voltage protection
- Built-in constant current limiting circuit
- 3 years warranty
